3-in-1 water filling machine

The image of CGF series washing-filling-capping 3-in-1 unit Main feature of this machine: The line is mainly used for washing,filling sealing carbon dioxide drink suchas carbon dioxidewatertea ,aerated mineral water and so on. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient,faster and more east.The main machine adopts advanced PLC control technology.The key electric ele-ments adopt international famous product. The main technological data:Model CGF 12-12-6 CGF 18-18-6 CGF 24-24-8 CGF 32 Production capacity 4000 8000 10000 14000 Number of bulking vales 12 18 24 32 Number of washing positions 12 18 24 32 Number of twist hijab 6 6 8 10 appliable Round and squareBottle diameter 50-90Bottle height 150-310Compressed air pressure (mpa) 0.3-0.7Water pressure of bottle washer (mpa) 0.25Total power(kw) 3.13 3.84 4.1 5.6 Outside dimension 1800*1500*2200 2430*1800*2250 3050*2060*2100 4050*2300*2100 Weight dimension (mm) 2500 3200 4000 5000
